Single Phase Power Meter
Product Details:
Single Phase Power Meter Price And Quantity
- 1-10 Unit
- 1000.00 - 3000.00 USD ($)/Unit
Single Phase Power Meter Trade Information
- 1000 Unit Per Month
- 3 - 4 Week
- All India
Product Description
Fostered with years of industry experience and market understanding, we are offering a wide range of Single Phase Power Meter. This power meter has the wave crest factor of the input current and is able to measure all the values within measuring ranges. It has the fastest auto-shift speed amongst other testers of the same level and the measuring span can be locked on rapidly to perform accurate power consumption analysis. Clients can avail this Single Phase Power Meter in various specifications to meet their requirements.
Features:
- Minimal maintenance
- Robust design
- Accurate results
Description:
Our offered Single Phase Power Meter 7110/7120 has the wave crest element of the input current as CF3 or CF9 and capable to measure each values within measuring spectrum. They have the quickest auto-shift speed amidst other testers of the equal level, and the measuring span can be keyed rapidly so as to perform precise power consumption analysis. The measuring array of both PM7110/7120 are 0.001W~16KW, and they are capable to measure Alternative Current (AC) power consumption containing Direct Current (DC) and get power factors with great accuracy at the time of analyzing the current indications from instruments with asymmetrical positive as well as negative waveforms. All the electronic instruments on the industry must adherence with EU needs for standby electric energy consumption, and the producers are producing their effort to move down it as best as they can. Single Phase Power Meter 7110/7120 are able to support the producers to measure energy & power consumption accurately and work long-hours survey with a PC.
Feature
- AC / DC Dual amp / watt-hour meter
- Wide range 0.001W ~ 16KW
- Connection software attached
- Standby Power D.P.I. of 0.001W
- With crest factor ratio display
- Up to the 50 levels harmonic wave analysis capability
- 1000 sets of measurement data storage space
Harmonics
| Analysis base | To achieved stable fundamental frequency analysis by voltage or current (non-inverter) |
| Frequency Range | 45Hz ~ 440Hz |
| FFT Data Length | 1024 |
| FFT Data Format | 32 bits |
| Measurement Projects | 1-50 THD, 1-50 level voltage and current V [n], A [n] |
Specification
| Model Name | 7110 | 7120 |
| Power Supply | Voltage 100 ~ 240Vac | |
|
| Frequency 50/60Hz | |
| Display | Seven-segment display | |
| Interface | RS232 | RS232+GPIB |
| Flash Memory | 6 Sets | |
| Environment | Temperature:23 ±5 Humidity: 20%~80% | |
| Dimension (W*H*D) | 335x103x335 mm | |
| Weight | 1.85 Kg | |
| Measurement bandwidth | DC 15Hz ~ 10KHz | DC 15Hz ~ 100KHz |
| Harmonic (Option) | Yes/NA | Yes/NA |
| Model | 7110-10K-HARM 7110-10K | 7120-100K-HARM 7120-100K |
| Fixture | F71201 TEST BOX | |
Range
| Current (fixed / auto) | 0.01A 0.03A 0.1A 0.3A 1A 3A 10A 20A |
| Voltage (fixed / auto) | 10V 30V 100V 300V 600V |
RMS/MEAN Mode Voltage & Current Accuracy (23 ±5)
| >=15 Hz, f 45Hz | ±(0.1% of reading + 0.4% of range) |
| >45 Hz, 66 Hz | ±(0.1% of reading + 0.1 % of range) |
| >66 Hz, 1 kHz | ±(0.1% of reading + 0.2 % of range) |
| >1 kHz, 10 kHz | ±(0.07*f % of reading + 0.3% of range) |
| >10 kHz, 100 kHz | ±(0.5% of reading + 0.5% of range) ±[{0.04×(f€“10)}% of reading] |
| F unit is 1KHz When the L-FILTER sets as ON:45Hz~66Hz frequency range allowable error-0.03 %~-0.05 of reading | |
| When the AC is measured, if the fundamental frequency exceeds 200Hz, the F-Filter is required to be turned off in order to measure the most accurate value When the frequency range is more than 10KHz, the 7120 starts to support | |
DC Mode Voltage & Current Accuracy(23 ±5)
| 10V~600V | ±0.2% reading ± 0.2% of range | 0.01A ~20A | ±{(0.2)% of reading + 0.2 % of range}±offset |
| To add up the OFFSET errors of various files during measuring the DC current | |||
Power (W) Accuracy (23 ±5)
| AC power ranges (Auto or Manual)(40 ranges) range up to 16KW | |
| |
| Incidental allowable error conditions | |
| Signal filter error (AC) | Frequencies between 45 to 66 Hz: Add 0.3% of reading |
| CF9 error (DC) | Add range tolerance * 3 |
| Accuracy effect of the phase error of the power | |
| |
| Error within 12 months | Add ±(0.5% of reading) |
Parameters Measurement Range
| Vrms | 0.1V ~ 600V | PF | 0.000 ~ ±1.000 |
| Vdc | 0.1V ~ 600V | Deg | -180°~ +180° |
| Irms | 0.1mA ~ 20A | THD | 0.01% ~ 99.99% |
| Idc | 0.1mA ~ 20A | Hz | 15Hz ~100kHz |
| W | 0.01W ~16KW |
|
|
