MT-6913 Motor Stator Testing System
Product Details:
- Color White
- Dimension (L*W*H) 337 x 145 x 522 Millimeter (mm)
- Product Type Stator Testing System
- Application For Industrial Use
- Material Aluminum
- Click to View more
MT-6913 Motor Stator Testing System Price And Quantity
- 1000.00 - 3000.00 INR/Unit
- 1 Unit
MT-6913 Motor Stator Testing System Product Specifications
- Aluminum
- White
- For Industrial Use
- Stator Testing System
- 337 x 145 x 522 Millimeter (mm)
MT-6913 Motor Stator Testing System Trade Information
- 1000 Unit Per Month
- 3 - 4 Week
- All India
Product Description
The MT-6913 Motor Stator Testing System puts the MT-6913 and the 6905 tester. This type of system is equipped with eight four-line free measurement test points and thirteenth channels. The testing projects that comprise the DC resistance tests which may find out the fault of copper wires that is over-tight at the time of winding and connecting/broken. Moreover, the Hipot testing on the desired protection standards, and the patron respect project of the Surge or Impulse are comprised as well. With the technically advanced Surge/Impulse instrument adopts waveform comparison so as to avoid the Corona Phenomenon that due to possible damage. This provides a total solution of standard test project to the world manufacturers and caters as a further tester for clients' products. The motor stator test systems, which is ideal for the programmable interface as well as the convenient operation can be swiftly imported into the output lines and the quality control center.
- Standard system is the Super Space-Saving Desktops Tester.
- Optional system is the Systematic Modular Cabinet Tester.
Features
- Both the internal wire resistance and the contact resistance will not affect the measurement. Using the 4-wire measurement will be more accurate than others
- To meet the standard test projects requirement of the international companies
- To control and analysis the programs will reduce the human careless and misjudgment
- Easy to edit environment and easy to learn
- It can test multiple sets of DUTs simultaneously(depending on the number of winding set of the product)
- When there are several DUTs are tested, it could identify the undesirable sets individually
- The Impulse/Surge with waveform comparison is a non-destructive analysis
- Maximum saved files will be up to 100 sets
- It provides the password function
- Speeding test could save time and improve efficiency
- Chinese/English screen could be switched arbitrarily
Measurement Data
| DCR | |
| Range | 0.1mΩ ~ 100KΩ (4-wire measurement) |
| Accuracy | Low Resistance：0.1mΩ ~ 1Ω ±( 0.2% ± 1mΩ) |
| Hipot | |
| Voltage | AC 0.1KV ~ 3KV DC 0.1KV ~ 3KV |
| Leakage Current | AC 0 ~ 10mA DC 0 ~ 5mA |
| Arcing | 0 ~ 9 |
| Measurement Time | 0.1 ~ 99.9 Continously Adjustable |
| Accuracy | 3% |
| IR | |
| Voltage | 100V ~ 1000V ±5% |
| Range | 1MΩ ~ 9.9GΩ |
| Measurement Time | 0.1 ~ 99.9 Continously Adjustable |
| Accuracy | 3% |
| Short Circuit | |
| Voltage | 0.2KV ~ 3KV ±2% |
| Measurement Item | Total Area、Area size comparison、Flutter、Waveform comparison、Corona |
| Accuracy | 2% |
Using the DCR 4-wire Measurement
Both the internal wire resistance and the contact resistance will not affect the measurement. Using the 4-wire measurement will be more accurate than others
Specification
| Channel | 13 channels |
| Indicator | Pass/Fail Screen Diaplay/Sound |
| Fixture | According to the test requirements |
| Power Supply | 90 ~ 132Vac or 198 ~ 264Vac (selectable) |
| Interface | RS-232 |
| Flash Memory | Storage of 100 rewritable data sets |
| Operation | Manual、RS-232 |
| Environment | Temperature : 10°C ~ 40°C Humidity : 20 ~ 90% |
| 6905 Dimension (W x H x D) / Weight | 435x133x525 mm / 12.5 Kg |
| 6913 Dimension (W x H x D) / Weight | 435x178x525 mm / 15 Kg |
| 6905 Display | 128*64 dot-matrix display |
| 6913 Display | 320*240 dot-matrix display |
Application
Motor
