5435 Transformer Tester

Product Description

5435 Transformer Tester

By deploying advanced patent, 5435 Transformer Tester is designed to match the requirements of transformers for multi-pin network communication with 20 test points and test frequency of 20Hz~200kHz. To intercept the installation interference from troubling measured points at the time of checking, the software has integrated function of top frequency compensation that enables the readings from attachment are almost the exact as measured points, which expand tester credibility. This is the best selection for transformer testing. These are used in web communication transformers, power transformers and many more.

Key Features:

• 0.1% Basic Accuracy
• 20Hz ~ 200KHz
• 4 Terminal BNC Guarded Connections
• 20 Channel fixture to test multi-pin transformer
• Test speed is 30 items / Sec
• Comprehensive Measurement Functions
• Straight Forward Intuitive Operation
• Can Pair with 100mA DC Bias
• Easily Programmed, De-skills Testing, Reduce Labor costs
• Unbeatable Performance, Speedy, Precise Accurate
• Secure, Tamper-Proof Programs
• GPIB, RS232 Interface, and USB interface to access information
• PC Link Software
• Convenient to Carry

Test Function

•  L, LK 0.1nH ~ 9999.99H
• C 0.01pF ~ 999.99mF
• Q, D 0.00001 ~ 99999
• Z,X,R 0.01m Ohm ~ 99.9999M Ohm
• Y 0.01nS ~ 99.9999S
• Angle -180ø ~ +180ø
• DCR 0.01m Ohm ~ 99.999M Ohm
• Turn 0.01 ~ 99999.99turns
• Pin-Short 12 pairs, between pin to pin
