6376 DIgital LCR Meter
Product Details:
- Usage For Industrial Use
- Color White
- Product Type LCR Meter
- Material Aluminum
- Accuracy 0.1 %
- Display Type Digital Only
- Click to View more
6376 DIgital LCR Meter Price And Quantity
- 1000.00 - 3000.00 USD ($)/Unit
- 1-10 Unit
6376 DIgital LCR Meter Product Specifications
- Aluminum
- White
- For Industrial Use
- 0.1 %
- LCR Meter
- Digital Only
6376 DIgital LCR Meter Trade Information
- 1000 Unit Per Month
- 3 - 4 Week
- All India
Product Description
The 6376 Digital LCR Meter, which is offered with great accuracy as well as speed. It is an economical and many function utility and is able to work the spare part & component test meticulously. It can set with Direct Current Bias. The friendly operation interface design of the LCR Meter is in adherence with the global trend and simple to run to import into the manufacturing lines swiftly. Synchronous tests with diverse settings of parameter. Because of the high level of precision values of analyzed data and the highest efficacy, it must be an essential testing tool of components as well as materials. 6376 LCR Meter is compatible to the interfaces of RS232, USB, LAN and GPIB PC connections.
Key Features:
- Basic accuracy up to 0.1%
- Synchronous tests with varied parameter settings
- Measurement of wide range of functions: Freq. to 5 Digits, signal level of 10mV to 2Vrms
- Collocating DC Bias to progressing current scanning analysis
- Fixture design capabilities, Specific customized services for clients
- LCR Meters are all compatible with convenient and efficient Meter Link Software
Measurement Data:
| Test Frequency | 20Hz-500KHz |
| Points Of Test Frequency | Continuity |
| Basic Accuracy | ± 0.1% |
| AC Drive Level | 10mV to 2Vrms (1m Vrms steps) |
| DC Drive Level | 0.01V~2V |
| Output Impedance | 100Ω |
| Frequency trimming resolution | 5 Digits |
| Frequency output accuracy | ± 0.01% |
| AC test speed (Max.) | 75mS |
| AC test speed (Fast) | 150mS |
| AC test speed (Medium) | 450mS |
| AC test speed (Slow) | 600mS |
| DC test speed (Max.) | 30mS |
| DC test speed (Fast) | 60mS |
| DC test speed (Medium) | 120mS |
| DC test speed (Slow) | 500mS |
| DC Bias Current Source | Option (Model 6220) |
Technical Specifications:
| Measured Value Detection Mode | Define upper and lower thresholds according to main and sub parameters |
| ESR | Series/Parallel |
| Mathematical Mode | Absolute/Percentage |
| Test Range | Automatic/Lock |
| Indicator | Pass/Fail/Bias LED and Built-in speaker |
| Output Terminal | BNC connector |
| Safety | EN61010-1 |
| Immunity | EN61326-1 |
| Emissions | EN55022 Class A |
| Calibration | Open Circuit / Short Circuit: Avoid the misreading caused by the stray capacitance from kelvin clips and fixtures |
| Auto-save when power-off function | When the power is turned off or encounter a power outage, all the data will be saved automatically and recovered when tester system is switched on again |
| Power Supply | Voltage 90-132Vac or 198-264Vac (selectable) |
|
| Frequency 47 ~ 63Hz |
| Display | 320x240 dot-matrix display |
| Interface | RS-232, GPIB (option), Handler (option) |
| Flash Memory | Built-in flash for storage of 64 groups of Multi-steps setting (Each group contains up to 30 steps) |
| Operation | Auto, Manual, RS-232, GPIB (option), Handler (option) |
| Environment | Temperature : 10°C to 40°C Humidity : 20 ~ 90% |
| Dimension (WxHxD) | 340x133x525 mm |
| Weight | 6.5 Kg |
Parameters Measurement Ranges:
| ｜Z｜ R X | 0.1 mΩ - 100MΩ |
| ｜Y｜ G B | 10nS - 1000S |
| Cs Cp | 0.01pF - >1F |
| Ls Lp | 0.01nH - 100KH |
| D | 0.00001 - 9.9999 |
| Q | 0.1 - 9999.9 |
| DCR | 0.1mΩ - 100MΩ |
| Δ% | -999.99% - 999.99% |
| Θ | -180° - +180° |
Applications:
Resistance, Capacitance, Inductance, Oscillators, Sensors, Delay Line, Filters, Resonators.
